# Electrical Calculation

We make a list of some common calculation formulas that you might use when choosing a solid state relay (SSR)/solid state module (SSM) or designing a circuit.

Attention: HUIMU Industrial (HUIMULTD) assumes no liability for errors in data nor in safe and/or satisfactory operation of equipment designed from this information.

## Electric Power Calculation Formulas

### ● Single Phase Load

P=U·I·cosφ

U is the Voltage (usually 220VAC), I is the Current.

### ● Three Phase Load

P=√3·U_{L}·I_{L}·cosφ=3·U_{P}·I_{P}·cosφ

U_{L} is the Line Voltage (normally 380VAC), I_{L} is the Line Current, U_{P} is the Phase Voltage (normally 220VAC), I_{P} is the Phase Current.

### ● Power Factor (cos φ)

If the load type is resistive load (such as electric heater), then cos φ=1; If the load type is inductive load (such as an electric motor), then 0<cos φ<1. Take electric motor as a example, when the electric motor is fully loaded, the active current is the largest, the reactive current is the smallest, and the power factor is about 0.85; when the load is light or no load, the active current is small, the reactive current is large, and the power factor is between 0.4 and 0.7. Thus, we usually take a power factor of 0.78 or 0.8. If the load type is capacitive load (such as power compensator), then cos φ<0.

### ● Peak Value, Effective Value, Average Value

The AC voltage is a sine wave, and its voltage value changes periodically from 0 to the maximum value (U_{MAX}), so its peak value (U_{PK}) is equal to the maximum value.
The AC effective value is specified by the thermal effect of the current, that is, let an AC current and a DC current pass through resistors with the same resistance value respectively, and if they generate equal heat in the same time, then the effective value of this AC current is equaled to the value of this DC current. Since the effective value of the sinusoidal AC voltage is equal to its root mean square value (U_{RMS} or U), U_{RMS} is generally used to represent the effective value of the AC voltage. Normally, the AC voltage value we detect through detection equipment (such as multimeters) is the effective voltage value, and the AC voltage value marked on the electrical equipment is also the effective value (such as 220VAC, 380VAC).
The average AC voltage (U_{AV}) is the average voltage value over a period. The average AC voltage is equal to the integral of the voltage in one cycle divided by 2π (the time in one cycle). Theoretically, the DC voltage value obtained after full-wave rectification of the AC voltage is equal to the average value of the AC voltage.

U_{PK}=√2·U_{RMS}=1.414·U_{RMS}

U_{AV}=2/π·U_{PK}=0.637·U_{PK}

Similarly, according to Ohm's law, we can get the peak value (IPK or IMAX), the effective value (IRMS), and the average value (IAV) of the AC current.

I_{PK}=√2·I_{RMS}=1.414·I_{RMS}

I_{AV}=2/π·I_{PK}=0.637·I_{PK}

Because the value of DC current or DC voltage is constant, they have no maximum value, effective value, and average value.

## Derating Factor Calculation Formulas

### ● Derating Factor

Since the performance of the solid state relay/solid state module is affected by the working environment and the load type, the Derating Factor (or Current Multiple Factor) should be considered when selecting the rated current value of the solid state relay/solid state module.

I_{R}=I_{L}/α

I_{R} is the rated current value of the solid state relay/solid state module;

I_{L} is the DC load current value or the AC load current effective value (rms value);

α is the derating factor.

According to the working environment of the solid state relay/solid state module (ventilation, temperature, service time, etc.), the derating factor can be divided into three levels: Protected, Normal and Severe.

For resistive loads (such as electric heater, incandescent lamp, etc.), α = 0.5 (Protected), α = 0.5 (Normal), α = 0.3 (Severe);

For inductive loads (such as motor, transformer, etc.), α = 0.2 (Protected), α = 0.16 (Normal), α = 0.14 (Severe);

For capacitive loads (such as power compensator, etc.), α = 0.2 (Protected), α = 0.16 (Normal), α = 0.14 (Severe).

### ● Current Multiple Factor

Current Multiple Factor is the inverse of Derating Factor.

I_{R}=I_{L}·β

I_{R} is the rated current value of the solid state relay/solid state module;

I_{L} is the DC load current value or the AC load current effective value (rms value);

β is the current multiple factor.

For resistive loads (such as electric heater, incandescent lamp, etc.), β = 2 (Protected), β = 2 (Normal), β = 3 (Severe);

For inductive loads (such as motor, transformer, etc.), β = 5 (Protected), β = 6 (Normal), β = 7 (Severe);

For capacitive loads (such as power compensator, etc.), β = 5 (Protected), β = 6 (Normal), β = 7 (Severe).

For example, if you need a DC to AC Panel solid state relay to switch a 220VAC, 10A resistive load, and require this solid state relay to work uninterrupted in a poor ventilation environment, then according the derating factor β = 3 (Severe), you should choose MGR-1D4830 (DC to AC, load: 480VAC, 30A).

## Varistor Calculation Formulas

If the load peak voltage is high, be sure to connect the varistor (such MOV, ZNR) in parallel to the output terminal of the solid state relay/ solid state module.

### ● Withstand Voltage

The withstand voltage formula of the varistor is: V_{imA}=V_{1mA}=(a·v)/(b·c)

V_{imA} is the varistor voltage when the current is XmA. Due to the current value is usually set at 1mA, it can also be expressed as V_{1mA}; a is the voltage fluctuation coefficient, generally 1.2; b is the varistor error value, generally 0.85; c is the aging coefficient of the component, generally 0.9; v is the DC operating voltage, or the AC rms voltage.

Therefore, the above formula can be simplified as:

For DC circuit，V_{imA}≈1.6·v

For AC circuit，V_{imA}≈1.6·V_{p}=1.6·√2·V_{AC}

V_{p} is the peak voltage, V_{AC} is the effective value.

Generally, the varistor voltage is 1.6 times the load voltage, but when the load is an inductive load, the varistor voltage should be 1.6-1.9 times the load voltage to ensure safety.

### ● Energy Absorption

The energy absorption formula of the varistor is: W=K·I·U·T

W is the energy absorbed by the varistor, and the unit is Joule (J); I is the peak current flowing through the varistor, and the unit is Ampere (A); U is the peak voltage across the varistor generated by the peak current, and the unit Is Volt (V); T is the duration of the peak current, and the unit is second (s). K is the waveform factor (if T=2ms, then K=1; if T=8/20us, then K=1.4; if T=10/100us, then K≈1.4).

## Rectifier Circuit Calculation Formulas

### ● Single-Phase Half-Wave Rectification Circuit

U_{0}=0.45·U_{2}

I_{0}=0.45·U_{2}/R_{L}

I_{V}=I_{0}

U_{RM}=√2·U_{2}

### ● Single-Phase Full-Wave Rectification Circuit

U_{0}=0.9·U_{2}

I_{0}=0.9·U_{2}/R_{L}

I_{V}=1/2·I_{0}

U_{RM}=2·√2·U_{2}

### ● Single-Phase Bridge Rectification Circuit

U_{0}=0.9·U_{2}

I_{0}=0.9·U_{2}/R_{L}

I_{V}=1/2·I_{0}

U_{RM}=√2·U_{2}

### ● Single-Phase Half-Wave Rectification Filter Circuit

U_{0}=U_{2}

I_{0}=U_{2}/R_{L}

I_{v}=1/2·I_{0}

U_{RM}=2·√2·U_{2}

C≥(3~5)·T/R_{L}

T=1/f, if f=50Hz, then T=1/50=20ms

### ● Single-Phase Full-Wave Rectification Filter Circuit

U_{0}=1.2·U_{2}

I_{0}=1.2·U_{2}/R_{L}

I_{v}=1/2·I_{0}

U_{RM}=√2·U_{2}

C≥(3~5)·T/2R_{L}

T=1/f, if f=50Hz, then T=1/50=20ms

### ● Single-Phase Bridge Rectification Filter Circuit

U_{0}=1.2·U_{2}

I_{0}=1.2·U_{2}/R_{L}

I_{v}=1/2·I_{0}

U_{RM}=√2·U_{2}

C≥(3~5)·T/2R_{L}

T=1/f, if f=50Hz, then T=1/50=20ms

### ● VDSM, VDRM, VRSM, VRRM

V_{RSM}=V_{RRM}+200V

V_{RSM} (Non-Repetitive Peak Reverse Voltage), is the maximum allowable surge value of reverse voltage that can be applied to the reverse direction of the device; V_{RRM} (Repetitive Peak Reverse Voltage), is the maximum allowable value of reverse voltage that can be repeatedly applied to the reverse direction of the device.

V_{DSM} =V_{DRM} +200V

V_{DSM} (Non-Repetitive Peak Off-State Voltage), is the maximum allowable surge value of off-state voltage that can be applied to the forward direction of the device; V_{DRM} (Repetitive Peak Off-State Voltage), is the maximum allowable value of off-state voltage that can be repeatedly applied to the forward direction of the device.

I_{t}^{2}=I_{TSM}^{2}·t_{w}/2

t_{w} is the half sine period; I_{TSM} it the maximum non-repetitive on-state surge current in one cycle; if the frequency is 50Hz, I_{t}^{2}=0.005 I_{TSM}^{2} (Amps^{2}·sec)

## Heat Generation Calculation Formulas

When the solid state relays are working, the output circuit has a voltage drop of 1~2V. When the solid state modules (or power modules) are working, the output circuit has a voltage drop of 2~4V. And the electrical energy they consume is transmitted as heat, and this heat is only related to their operating current. The solid state relay has a calorific value of 1.5 watts per ampere (1.5 W/A) and the solid state module has a calorific value of 3.0 watts per ampere (3.0 W/A). The heat generated by the three-phase circuit is the sum of the heat generated by each phase.

Single Phase or DC solid state relay: P=1.5·I

Single Phase or DC solid state module: P=3.0·I

P is the heat generated by solid state relay/solid state module, and the unit is W; I is the actual load current, and the unit is A.

Normally, if the load current is 10A, a heat sink must be equipped. If the load current is 40A or higher, an air-cooled or water-cooled heat sink must be equipped.

## Heat Dissipation Calculation Formulas

The heat dissipation performance of the heat sink is related to its material, shape, temperature difference, and etc.

Q=h·A·η·ΔT

Q is the heat dissipated by the heat sink; h is the total thermal conductivity of the heat sink (W/cm^{2}·°C), generally aluminum material is about 2.12W/cm^{2}·°C, the copper material is about 3.85W/cm^{2}·°C, and the steel material is about 0.46W/cm^{2} °C; A is the surface area of the heat sink (cm^{2}); η is the heat sink efficiency, which is mainly determined by the shape of the heat sink; ΔT is the difference between the maximum temperature of the heat sink and the ambient temperature (°C).

Therefore, it can be obtained from the above formula that the larger the surface area of the heat sink is, the larger the difference from the ambient temperature is, and the better the heat dissipation performance is.

## Common Unit Conversion

1MΩ=10^{3}kΩ=10^{6}Ω=10^{9}mΩ

1F=10^{3}mF=10^{6}μF=10^{9}nF=10^{12}pF

1H=10^{3}mH=10^{6}μH

1MV=10^{3}kV=10^{6}V=10^{9}mV=10^{12}μH

1kA=10^{3}A=10^{6}mA=10^{9}μA

1W=10^{3}mW=1J/s=1V·A

1HP=0.75kW

1kW·h=10^{3}W·h=10^{3}V·A·h=10^{6 }V·mA·h=3.6·10^{6}J

1cm=10mm=0.39in

1cm^{2}=0.16sq in

°F=1.8°C+32

K=°C+273.15

The above content was updated on April. 18, 2022.

There may be errors and omissions during the content collation and upload process, so all things above are for reference only. If you find any problems, your correction will be grateful.
